12-bit Temperature Smart Sensor (17 meter)

Sensors

12-bit Temperature Smart Sensor (17 meter)

  • Vendor:Onset

Availability: Available Item
$230.00
Qty Price
Buy 1 $230.00 ea
Buy 10 $218.50 ea

Overview

The 12-bit Temperature Smart Sensor provides < ± 0.2° C total accuracy (< ±0.36° F) and resolution of < ± 0.03° C (< ±0.054° F) over the range of from 0° to 50° C (32° to 122° F). The full measurement range is -40° to 100° C (-40° to 212° F). A selectable measurement-averaging feature further improves accuracy. Reliable service is assured by a stainless steel sensor tip and robust cable rated for immersion in water up to 50° C for up to 1 year. This model has a cable length of 2m.

Highlighted Features

  • Measurement range of -40° to 100°C (-40° to 212°F)
  • Stainless steel sensor tip
  • Sensor and cable rated for immersion in water or soil up to 50°C for up to 1 year

In what environment does this sensor operate?

This sensor operates in indoor, outdoor and underwater environments.

What measurements does this sensor support?

This sensor supports the following measurements: Temperature and Water Temp

Measurement range: -40° to 100°C (-40° to 212°F) sensor tip*
Accuracy: < ±0.2°C from 0° to 50°C (< ±0.36°F from 32° to 122°F)
Resolution: < ±0.03°C from 0° to 50°C (< ±0.054°F from 32° to 122°F)
Drift: < ±0.1°C (0.18°F) per year
Response time: < 3 minutes typical to 90% in 1 m/sec air flow
< 30 seconds typical to 90% in stirred water
Measurement averaging option: Yes
Environmental rating: Waterproof sensor tip and cable rated for 1-year immersion in water up to 50°C
Housing: Stainless steel sensor tip
Dimensions: 5.1 x 33 mm (0.2 x 1.3 inches)
Approximate weight: 100 g (1 oz), 310 g (4 oz), 880 g (12 oz) "‚¬? varies with cable length
Cable lengths: 2.0 m (6.6 ft), 6.0 m (19.7), 17 m (55.8ft)
Number of data channels: 1
Length of Smart Sensor network cable: 0.5 m (1.6 ft)
* Sensor tip and cable immersion in fresh water up to 50°C (122°F) for one year. Cable electronics are rated for up to 75°C (167°F). Radiation Shield strongly recommended
for use in sunlight (part # RS3)

- The CE Marking identifies this product as complying with all relevant directives in the European Union (EU)
